i3200 Printerhead

Ink Type

UV

Eco Solvent

Aqueous

Type

PrecisionCore MicroTFP printhead

WidthxDepthxHeight

69.1x 59.4 x 35.6 mm

Weight

82 g

Number of Nozzle

3200

Nozzle pitch/nozzle row

1/300 inch

Nozzle rows

8 rows

Nozzle Resolution

300 npi /row 600 npi/2 rows

Max. number of colour inks

4 colours

Effective print width Systems

33.8 mm (1.33 inches)

Jetting frequency

43.2 kHz (Single mode)

21.6 kHz (Multi mode)

Droplet volumes

5 pl (Single mode)

6 pl (Single mode)

6 pl (Single mode)

6, 12.5 pl (Multi mode)

6.3,1 2.3 pl (Multi mode)

6.3,1 2.3 pl (Multi mode)

Viscosity range

5-7 mPa･s

3-4 mPa･s

3-4 mPa･s

Positioning Mechanism

Reference hole
